HP 9845 CPU

HP 9845 CPU

HP 9845 CPU
Notes:This is the CPU of a HP 9845 desktop calculator/computer. It's a 16 bit NMOS processor that consists of three separate LSI MOS chips and 4 bipolar chips mounted
all together in a hybrid circuit. Runs at 1 - 10 MHz depending on the model. It is described in the issue #06, year 1976, of the HP Journal (freely available online at /UMMR
Date: 15.10.2007 11:16
Photo contributed by: UMMR
